Customized Laser Systems
.png/:/rs=w:600,h:600,cg:true,m/cr=w:600,h:600)
We specialize in developing and producing tailor-made laser solutions to address the unique requirements of our clients. With in-depth expertise in solid-state lasers, we play an active role in supporting scientific, medical, and industrial research projects. Our extensive experience working in research institutions has provided us with a comprehensive understanding of the challenges researchers face when selecting the appropriate equipment for their work. Factors such as budget constraints, the need for lasers with various wavelengths, specific technical demands, tight project deadlines, and limited laboratory space often pose significant challenges to achieving ambitious research goals. To assist our clients in overcoming these obstacles, we offer a Custom Laser Solutions Program. This program delivers laser systems designed to meet precise specifications and fulfill distinct operational needs. In developing custom systems, we draw on the expertise of our engineers and scientists, utilizing both modular components from existing products and modified serial lasers. This strategy not only accelerates project timelines but also ensures the reliability and performance of established products. Our custom laser systems come with the same warranty and dependable service as our standard offerings.
- Spectral range from 0.2 to 20 μm
- Fixed wavelengths or continuously tuneable radiation
- Spectral linewidth down to 0.05 cm-1
- Femto-, pico-, nano-, micro- and millisecond pulse durations
- Laser pulse energies from dozens of nJ up to 100 J
- Diode-pumped lasers and high-power lamp-pumped lasers
- Pulse repetition rate from single pulses to 70 MHz
- Built-in wavelength meters and energy meters
- Automated change of operating wavelengths and full PC control
Description
ARCHITECTURE AND DESIGN PRINCIPLES
3D laser system for optical measurements and plasma generation in solids, liquids, and gases.
IR tunable laser system for detecting explosives, toxins, and narcotics.
We provide laser output with fixed wavelengths or continuous tuning from 0.2 μm to 20 μm by combining advanced laser media and nonlinear crystals. Our systems are typically built using Nd:YAG lasers, Ti:Sapphire lasers, OPO with harmonic generators, and sum/difference-frequency generators based on various crystals such as BBO, KTP, KTA, AgGaSe2, and ZGP.
IR tunable laser system for detecting explosives, toxins, and narcotics.
3D laser system for optical measurements and plasma generation in solids, liquids, and gases.
IR tunable laser system for detecting explosives, toxins, and narcotics.
- Tuning range: 3..5 μm and 8..12 μm
- Pulse energy up to 25 mJ
- Pulse repetition rate 100 Hz
3D laser system for optical measurements and plasma generation in solids, liquids, and gases.
3D laser system for optical measurements and plasma generation in solids, liquids, and gases.
3D laser system for optical measurements and plasma generation in solids, liquids, and gases.
- Output wavelength: 213 nm, 355 nm, 532 nm and 1064 nm
- Pulse energy up to 1.4 J
- Pulse repetition rate 10 Hz
- Pulse width 10 ns
Laser system for PIV applications
Multifunctional tuneable narrow linewidth laser system
3D laser system for optical measurements and plasma generation in solids, liquids, and gases.
- Output wavelength 532 nm
- Pulse repetition rate 100 Hz
- Pulse energy 100 mJ
Options:
- Output wavelength 1064, 532, 355, 266 nm
- Output pulse energy up to 1,3 J (each channel)
Multifunctional tuneable narrow linewidth laser system
Multifunctional tuneable narrow linewidth laser system
Multifunctional tuneable narrow linewidth laser system
Pulse energy
- 532 nm …………………………….. 0 – 500 mJ
- 700…980 nm ……………………. up to 110 mJ
- 350…490 nm ……………………. up to 40 mJ
- 235…320 nm ……………………. up to 15 mJ
- 210…235 nm ……………………. up to 6 mJ
- linewidth …………………..less than 0,005 nm
- Pulse repetition rate ………………..10 Hz
High power 532nm laser system
Multifunctional tuneable narrow linewidth laser system
Multifunctional tuneable narrow linewidth laser system
- Wavelength 532 nm
- Pulse repetition rate 10 Hz
- Pulse energy 1200 mJ
- Pulse width 13 нс
Options:
- Output wavelength 1064 nm or 266 nm
Laser system for simulating ionizing radiation effects on semiconductor microstructures.
- Output wavelength 1064 nm and 532 nm
- Pulse repetition rate 20 Hz
- Pulsewidth 10 ns
- Mirror articulated arm is user as a beam delivery system
IR Laser system for DIAL applications
The laser system used to measure the atmospheric concentrations of gases such as water vapor, CO2, N20, NO2, etc.
- Tuning range: 3…4 μm
- Linewidth < 1 cm-1
- Output pulse energy 6 mJ
- Pulse repetition rate 20 Hz
- Divergence < 2 mrad
Three-Wave Laser System
Three-Wave Laser System
The laser system provides output radiation at 1064 nm, 532 nm and 355 nm (or 266 nm) with smooth pulse energy adjustment from 0 to 100 mJ and is intended for remote sensing and location of various objects.
- Output wavelength: 355 (or 266) nm, 532 nm and 1064 nm
- Pulse energy up to 100 mJ
- Pulsewidth 10 ns
- Beam pointing stability at changing output wavelength < 0.2 mrad
